UNI-T LM320E Digital Angle Meter

Description

UNI-T LM320E Digital Angle Meter

The UNI-T LM320E is a compact, portable digital angle meter built with an aluminum-alloy + ABS body for durability and light weight. It provides omnidirectional 4×90° angle measurement with a high-definition backlit screen and automatic screen rotation, delivering clear real-time tilt readings in multiple units (°, %, mm/m, in/ft). The LM320E adds laser indication to assist alignment and direction-finding, making it easier to mark or sight reference lines on workpieces.

Designed for workshop and field use, the LM320E offers both absolute and relative angle modes (you can set 0° at any position) and a data-hold / data-lock function for capturing measurements. It is powered by a rechargeable 3.7 V, 1000 mAh lithium battery with Type-C charging, so you can recharge on the job without swapping cells. Auto power-off preserves battery life when idle.

The unit’s two-sided magnetic base gives stable attachment to metal surfaces and frees your hands during layout tasks. With a compact footprint (≈83.5 × 70 × 35.5 mm) and consumer-laser safety class 2, the LM320E is suited for construction, mechanical installation, woodworking, and automotive alignment work where quick, repeatable angle checks and simple laser-assisted alignment are needed.

Features:

• 4×90° omnidirectional angle measurement.
• High-definition backlit screen with automatic rotation.
• Relative and absolute angle measurement; 0° can be set at any position.
• Built-in laser indication (2 laser lines on LM320E).
• Two-sided magnetic base for secure attachment.
• Rechargeable 3.7 V 1000 mAh lithium battery with Type-C charging.
• Data-hold / data-lock function.
• Auto power-off for energy saving.

Specifications:

Applications:

• Building construction.
• Mechanical installation.
• Wood processing / woodworking.
• Automotive industry (alignment and measurement).

Package Contents:

• 1x Angle Meter
• 1x Type-C charging cable
• 1x Gift box
• 1x User manual
