Name: UNI-T UT12E-ROW AC Voltage Detector
SKU: UT12E
Availability: InStock

UNI-T UT12E-ROW AC Voltage Detector

525 EGP

UNI-T UT12E-ROW is a rugged non-contact AC voltage detector (24Ã¢â‚¬â€œ1000V) with LED, buzzer, vibration, flashlight, IP67 protection and 2 m drop resistance.

Description

The UNI-T UT12E-ROW AC Voltage Detector is a reliable and user-friendly tool designed for both professionals and DIY enthusiasts to safely detect the presence of AC voltage in various electrical systems. Featuring a compact design, this voltage detector offers clear visual and audible alerts, allowing users to quickly identify live wires and potential hazards. Its durable construction ensures longevity, making it suitable for a range of applications, from home maintenance to industrial use. With its intuitive operation and essential safety features, the UNI-T UT12E-ROW is an essential addition to any toolkit for effective electrical troubleshooting.

UNI-T UT12E-ROW AC Voltage Detector

The UNI-T UT12E-ROW is a professional-grade non-contact AC voltage detector designed for safely detecting the presence of alternating voltage in wires and electrical installations without making direct contact. Its body is rugged and sealed to resist dust and moisture (IP67 rating), making it suitable for light industrial or field environments. The detector fits like a pen or small probe, allowing the user to move along cables, wall outlets, conduits, or junction boxes to sense live voltage via visual, audible, and vibration cues.

Internally, the UT12E-ROW senses the electric field emitted by AC voltage above a threshold. It alerts the user through a buzzer, LED indicator, and optional vibration feedback. The unit also includes a built-in flashlight for illuminating test points in dim or enclosed spaces. The design supports dual voltage modes (low and high sensitivity) to pick up both weak and strong AC signals, allowing flexible use depending on the wire under test.

In practice, this detector becomes a go-to safety tool for electricians, maintenance staff, and technicians before they work on wiring or electrical circuits. It helps to confirm whether a wire is live, identify phases or line presence, and provides a rapid check before engaging hands-on work. Because it is non-intrusive, compact, and robust, it serves as a convenient first line of defense for detecting dangerous voltage in residential, commercial, or industrial settings.

Features:

Non-contact AC voltage detection.
Dual sensitivity modes (low / high voltage).
LED indicator (visual).
Audible buzzer alert.
Vibration feedback (optional).
Built-in flashlight.
Auto power-off.
Low battery indication.
Rugged IP67 dust / water protection.
Drop resistance (2 m).

Specifications :

Specifications	UT12E-ROW
AC voltage (Low)	24V~1000V
AC voltage (High)	90V~1000V
Frequency range	50/60Hz
Vibration mode	√
Built-in ﬂashlight	√
※Audible (buzzer) and visual (LED) indication	√
Buzzer	√
LED indication	√
Auto power oﬀ	√
Low voltage indication	√
Double injection molding	√
Drop test	2m
General Characteristics
Power	1.5V battery (R03) x 2
Product color	Red and grey
Product net weight	72g
Product size	160.5mm x 21.5 mm x 25mm

Applications:

Low-voltage circuit detection.
High-voltage / panel wiring checks.
Pre-work safety voltage verification.
Maintenance & fault finding in wiring systems.

Package Contents:

1x UT12E-ROW AC voltage detector (main unit)
2x Batteries (AAA / R03)
1x English user manual / instruction guide
1x Blister / retail packaging

Documents:

Datasheet
User Manual

Click to enlarge

Back to products

Add to wishlist

Compare

SKU: UT12E Categories: Digital Multimeters & Data Logging, Measuring Instruments, UNI-T Tags: electrical tools, electronics testing, measurement tools, test equipment, uni-t

Specifications	UT12E-ROW
AC voltage (Low)	24V~1000V
AC voltage (High)	90V~1000V
Frequency range	50/60Hz
Vibration mode	√
Built-in ﬂashlight	√
※Audible (buzzer) and visual (LED) indication	√
Buzzer	√
LED indication	√
Auto power oﬀ	√
Low voltage indication	√
Double injection molding	√
Drop test	2m
General Characteristics
Power	1.5V battery (R03) x 2
Product color	Red and grey
Product net weight	72g
Product size	160.5mm x 21.5 mm x 25mm
