Name: UNI-T UT89X Digital Multimeter
SKU: UT89X
Availability: InStock

UNI-T UT89X Digital Multimeter

1,125 EGP

UNI-T UT89X digital multimeter offers accurate measurements for voltage, current, resistance, and more, with advanced features for professionals and DIY projects.

Description

The UNI-T UT89X Digital Multimeter is a versatile and reliable tool designed for both professionals and DIY enthusiasts, offering precise measurements for voltage, current, and resistance. Featuring a clear LCD display, this multimeter allows for easy reading of results, while its compact design ensures portability and convenience. With a range of functions, including diode testing and continuity checking, the UT89X is suitable for a variety of applications, making it an essential addition to any toolkit. Its user-friendly interface and durable construction provide a dependable solution for accurate electrical diagnostics and troubleshooting.

UT89X Series Digital Multimeters

UT89X/UT89XD is a reliable hand-held 3 5/6 bit digital multimeter with true RMS sine wave measurement. It can measure Max. 1000V DC/AC voltage, Max. 20A DC/AC current, resistance, capacitance, frequency, diode, hFE, continuity and NCV, quickly distinguishing between neutral and live wires accurately.

UT89X can measure temperature and detect neutral and live wires with a test lead. UT89XD can perform LED test. Equipped with audible and visible alarm, flashlight and auto backlight functions, this series can be used in dark environment. It attracts users with its bi-color durable case, modern exterior and multiple functions.

Features:

1000V AC/DC； 20A AC/DC
True RMS, 6000 count
Dual range NCV test which quickly identifies neutral and live wires through light intensity
Audible/visual alarm
Capacitor charging indicator
Ergonomic design
Double injection molding
1m drop proof
Flashlight: Auto backlight

Specifications:

Specifications	Range	UT89X
DC voltage (V)	600mV/6V/60V/600V/1000V	±(0.5%+2)
AC voltage (V)	6V/60V/600V/1000V	±(0.8%+5)
DC current (A)	60μA/60mA/600mA/20A	±(0.8%+8)
AC current (A)	60mA/600mA/20A	±(1%+12)
Resistance (Ω)	600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ	±(0.8%+3)
Capacitance (F)	100mF	±(2.5%+20)
Frequency (Hz)	9.999Hz/9.999MHz	±(0.1%+4)
Duty cycle	0.1%~99.9%	±(2%+5)
Temperature (℃)	-40℃~1000℃	±(2%+4)
Temperature (℉)	-40℉~1832℉	±(2%+8)
Live wire test		√
Audible/visual alarm	V/A/Cap/Diode	Live/hFE/NCV
Transistor Hfe		√
Dual range NCV test		√
Flashlight		√
General Characteristics
Power	1.5V battery (R03) x 4
Display	61mm x 36mm
Product net weight	345g
Product size	189mm x 89mm x 53mm

Applications:

Electrical System Troubleshooting.
HVAC System Diagnostics.
Automotive Electrical Testing.
Industrial Equipment Maintenance.
Home Electrical Inspections.

Package Contents:

1× UNI-T UT89X Digital Multimeter
1× Test Lead Set
1× Temperature Probe
1× User Manual
1× Carrying Case

Documents:

Datasheet
User manual

Click to enlarge

Back to products

Add to wishlist

Compare

SKU: UT89X Categories: Digital Multimeters & Data Logging, Measuring Instruments, UNI-T Tags: digital multimeter, electrical testing, electronics measurement, uni-t, voltage meter

Specifications	Range	UT89X
DC voltage (V)	600mV/6V/60V/600V/1000V	±(0.5%+2)
AC voltage (V)	6V/60V/600V/1000V	±(0.8%+5)
DC current (A)	60μA/60mA/600mA/20A	±(0.8%+8)
AC current (A)	60mA/600mA/20A	±(1%+12)
Resistance (Ω)	600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ	±(0.8%+3)
Capacitance (F)	100mF	±(2.5%+20)
Frequency (Hz)	9.999Hz/9.999MHz	±(0.1%+4)
Duty cycle	0.1%~99.9%	±(2%+5)
Temperature (℃)	-40℃~1000℃	±(2%+4)
Temperature (℉)	-40℉~1832℉	±(2%+8)
Live wire test		√
Audible/visual alarm	V/A/Cap/Diode	Live/hFE/NCV
Transistor Hfe		√
Dual range NCV test		√
Flashlight		√
General Characteristics
Power	1.5V battery (R03) x 4
Display	61mm x 36mm
Product net weight	345g
Product size	189mm x 89mm x 53mm
