UNI-T LM60Mi Mini Laser Distance Meter

Description

UNI-T LM60Mi Mini Laser Distance Meter
The UNI-T LM60Mi is a palm-sized laser distance meter that blends precision engineering with intuitive usability. Housed in a slim, metal-textured body barely larger than a matchbox, it slips easily into a pocket or clips onto a belt via its discreet hand-strap loop. A crystal-clear, backlit LCD presents distance readings in real time even in dimly lit spaces while simple, ergonomically placed buttons allow one-handed operation without fumbling or second-guessing. Inside, a high-accuracy optical sensor and refined laser emitter work together to deliver rapid, stable measurements across a broad working range, tacking on advanced Pythagorean calculations for indirect height and diagonal estimations without the need for added tools.

Powering the unit is a rechargeable lithium-ion cell that charges conveniently via Type-C connection, ensuring the meter is ready for hundreds of measurement cycles on a single charge. Its continuous-scan mode tracks dynamic changes in installation or alignment tasks, while automatic shut-off preserves battery life when left idle. Despite its miniaturized form, the LM60Mi feels robust in hand, offering a reassuring weight and tactile finish that resist slips and scuffs on job sites. With responsive feedback and instant readouts, this device turns complex layouts, leveling, and spatial planning into a smooth, one-step process making it a versatile companion for professionals and hobbyists alike.

Features:
Multiple Measurement Modes: supports single-distance, continuous-scan, area, perimeter, volume and Pythagorean (indirect height/diagonal) calculations.
High-Accuracy Optic Sensor: ensures measurement error is kept below ±2 mm.
Self-Calibration: automatic zero-point adjustment for consistent precision.
LCD Backlight: clear readout in low-light conditions.
Auto Laser Shut-Off: conserves battery and meets safety class requirements.
Auto Power-Off: extends standby life when idle.
MAX/MIN Tracking: captures extreme values during continuous measurements.
Unit Switch: toggle between meters, inches, and feet for versatile usage.
Specifications:
Parameter Specification
Measurement Range: 0.05 – 60 m
Accuracy: ±(2.0 mm + 5 × 10–5 × D)
Laser Class & Type: Class II; 630–670 nm, < 1 mW
Unit Selection: meters (m), inches (in), feet (ft)
Power Supply: 3.7 V, 370 mAh rechargeable Li-ion battery
Battery Life: Up to 8 000 measurements per full charge
Operating Temperature: 0 °C – 40 °C
Storage Temperature: –20 °C – 60 °C
Storage Humidity: 20 % – 80 % RH
Product Dimensions (L × W × H): 86.5 × 36.5 × 19.5 mm
Net Weight: 75 g
Auto Laser Shut-Off: Yes
Auto Power-Off: Yes
Applications:
Interior Design and Renovation.
Construction and Carpentry.
Real Estate and Property Management.
DIY Projects and Home Improvement.
Engineering and Surveying.
HVAC and Electrical Installation.
Warehousing and Logistics.

Package Include:
1x UNI-T LM60Mi Mini Laser Distance Meter unit
1x USB Type-C charging cable
1x User manual
1x Hand strap
1x Gift box packaging
