UNI-T UT305C+ Infrared Thermometers
The UNI-T UT305C+ is a professional-grade, non-contact infrared thermometer designed for rapid and reliable surface temperature measurements in challenging industrial settings. Its gun-style form factor offers comfortable handling during prolonged use, while an integrated laser pointer assists in precise targeting of small or distant objects. The instrument employs advanced infrared sensing technology to capture accurate readings without physical contact, making it ideal for monitoring hot, hard-to-reach, or potentially hazardous surfaces. A bright 2.4-inch TFT LCD presents temperature data clearly, even under varied lighting conditions, and intuitive controls allow users to navigate menus and lock readings effortlessly.
Encased in a rugged housing, the UT305C+ withstands everyday handling and minor impacts, ensuring long-term durability in workshop or field environments. It features onboard data logging with substantial internal memory, enabling storage of hundreds of measurements for later review. USB connectivity allows quick transfer of recorded data to a computer for analysis and reporting. The thermometer’s high distance-to-spot ratio of 55:1 facilitates accurate readings from a safe distance, and its wide measurement range (–50 °C to 1850 °C) accommodates both low-temperature diagnostics and high-temperature processes.
Overall, the UT305C+ balances precision, portability, and robustness, making it an indispensable tool for professionals requiring fast, non-contact temperature assessment across diverse applications.
Features:
- °C/°F selectable units.
- Audible buzzer alarm.
- Real-time clock and date display.
- “Infrared Professional” measurement mode.
- Surface heat-conduction detection mode.
- Surface dew-point detection mode.
- Surface temperature comparison mode.
- Trigger-lock function for continuous measurements.
- Reservation measurement capability.
- Storage for up to 999 data groups, with PDF and CSV export support.
- High-precision display of ambient temperature, relative humidity, dew-point temperature, and wet-bulb temperature.
- Integrated Type K thermocouple temperature measurement capability.
Specifications:
| Specification |
Details |
| Infrared Temperature Range: |
–50 °C to 1850 °C (–58 °F to 3362 °F) |
| Infrared Accuracy: |
±1.0 °C or ±0.01×T °C (whichever is greater) |
| Ambient Temperature Range: |
–10 °C to 50 °C |
| Ambient Temperature Accuracy: |
0 °C–40 °C: ±0.5 °C / –10 °C–0 °C & 40 °C–50 °C: ±1.0 °C |
| Relative Humidity Range: |
10 % RH to 90 % RH |
| Relative Humidity Accuracy: |
±5 % RH |
| Type K Thermocouple Range: |
–50 °C to 1370 °C |
| Type K Thermocouple Accuracy: |
±(0.5 %×T + 1.5) °C |
| Spectral Response: |
8 µm to 14 µm |
| Display Resolution: |
0.1 °C |
| Adjustable Emissivity: |
0.1 to 1.0 |
| Temperature Coefficient: |
±0.1 °C/°C or ±0.1 % °C/°C (whichever is greater) |
| Repeatability (Infrared): |
±0.5 %×T °C or 1 °C (whichever is greater) |
| Distance-to-Spot Ratio (D:S): |
55 : 1 |
| Laser Targeting: |
Single laser, < 1 mW output, Class II |
| LCD Display: |
2.4 inch TFT, 320 × 240 pixels |
| Type K Thermocouple Probe: |
1 m (40 in) cable with bead probe (standard micro connector) |
| USB Communication: |
Built-in micro USB port for data transfer |
| Drop Resistance: |
Survives a 1 m drop onto a hard surface |
Applications:
- Industrial Equipment Maintenance.
- HVAC System Diagnostics.
- Power Distribution Inspection.
- Automotive Diagnostics.
- Food Safety and Processing.
- Fire Prevention and Safety Monitoring.
- Laboratory and Research Use.
- Building and Home Inspection.
Package Contents:
- UNI-T UT305C+ Infrared Thermometer
- 9V Battery
- USB Cable
- Professional Carrying Case
- User Manual
- Quick Start Guide
- Calibration Certificate
- Wrist Strap
UNI-T UT305C+ Documents:
