Name: UNI-T UT3516+ Micro Ohm Meter
SKU: UT3516
Availability: InStock

UNI-T UT3516+ Micro Ohm Meter

30,000 EGP

The UNI-T UT3516+ Insulation Resistance Tester is a high-accuracy tool designed for reliable insulation and electrical safety testing. Ideal for power equipment, motors, cables, and industrial installations, it delivers stable, precise readings to help detect insulation faults and prevent failures. With a rugged handheld design, easy operation, and professional performance, the UT3516+ is the smart choice for electricians and technicians who need dependable insulation testing and confident results.

Description

The UNI-T UT3516+ Micro Ohm Meter is a reliable and precise instrument designed for measuring low resistance values, making it an essential tool for electrical engineers and technicians. With its user-friendly interface and clear digital display, this micro ohm meter allows for accurate readings in various applications, including testing connections, cables, and components. Built with durability in mind, the UT3516+ features a robust design that ensures long-lasting performance in demanding environments. Its compact size makes it easy to handle and transport, making it a practical addition to any toolkit for professional or industrial use.

UNI-T UT3516+ Micro Ohm Meter

The UNI-T UT3516+ Micro Ohm Meter is part of the UT3510+ series of benchtop Micro Ohm Meters that includes the UT3513+ and UT3516+ models. 4.3-inch LCD display. With high precision, high resolution and high speed measurement characteristics, with the highest accuracy of 0.05%, the minimum resolution of 1 μΩ. UT3516 + standard RS-232C, RS485, LAN port and HANDLER communication interface, support for SCPI and MODBUS RTU protocols, and can be with the computer, PLC or WINCE device communication, and efficiently complete the remote control and data acquisition functions.

Features

Multiple test modes

R/R-T/T/LPR/LPR-T four modes can be selected, LPR is a low-voltage test mode, can effectively protect the DUT.

6 bins comparator

The built-in comparator gears allow the setting of 6 comparison results. The component under test can be divided into 7 bins (BIN1, BIN2, BIN3, BIN4, BIN5, BIN6 and NG).

Logging and statistics

Logging: Up to 10000 groups of data can be recorded.
Statistics: up to 10,000 sets of data, process capability index calculation possible

Temperature correction and conversion

Temperature correction: Compensates for deviations in measured values due to temperature.
Temperature conversion: The difference between the internal temperature of the DUT and the ambient temperature can be obtained through the thermal effect of the resistor.

Specifications

Specification	Value
Model	UT3516+
Measuring Range	1 μΩ ~ 2 MΩ
Max. Test Rate	100 rdgs/s
Connectivity	RS232, RS485, HANDLER, LAN
Size	½ 2U
Display	4.3” TFT LCD

Applications

Quality control in manufacturing processes.
Testing of electrical components and materials.
Integration into automated test systems.
Laboratory research requiring precise low-resistance measurements.
Maintenance and inspection of electrical equipment.

Documents

UT3510-Series-Micro-Ohm-Meters-Data-Sheet UT3510-Series-Micro-Ohm-Meters-Programming-Manual

UT3510-Series-Micro-Ohm-Meters-QuickStart-Guide

UT3510-Series-Micro-Ohm-Meters-User-Manual
